Power amplifiers stereo — Ati (Audio Technologies Inc.) AT2007
Description, images, technical data and specifications
Ati (Audio Technologies Inc.) AT2007
Image source — © Ati (Audio Technologies Inc.)
This amplifier is so powerful that at its peak it may not have enough power from a 15 amp network. A network cable designed for a 20 amp connection also makes the connection more reliable than a 15 amp one.
Specifications
Model name
AT2007
Input sensitivity (mV)
N/A
Input impedance (balanced) (Ω)
28 000
Input impedance (single-ended) (Ω)
28 000
Output impedance (balanced) (Ω)
N/A
Output impedance (single-ended) (Ω)
N/A
Max current (A)
N/A
Output power (8Ω) (W)
200
Output power (4Ω) (W)
300
Gain (dBu)
34 (XLR), 28 (RCA)
Frequency response low +/- 3dB (Hz)
20
Frequency response high +/- 3dB (Hz)
20 000
Signal to Noise Ratio (dB)
120
Total Harmonic Distortion + Noise (0% global feedback) (%)
N/A
Total Harmonic Distortion + Noise (100% global feedback) (%)
0.03
Max power consumption (W)
N/A
Damping factor
400
Dimensions (mm)
432 х 178 х 465
Weight (kg)
22.7 - 42.3
Official link
