Power amplifiers stereo — Moon by Simaudio 461
Description, images, technical data and specifications
Moon by Simaudio 461
Image source — © Moon by Simaudio
The Moon 461 stereo power amplifier has become the most powerful amplifier in the Compass collection. It is designed to amplify the signal as precisely as possible, while maintaining dynamics, transparency and control, even when working with complex acoustics. The amplifier is based on the proprietary Moon Distortion-Canceling Amplifier (MDCA) architecture, first used in the elite North Collection series. This technology significantly reduces distortion and increases the linearity of the signal, ensuring accurate and clean reproduction.
Specifications
Model name
461
Input sensitivity (mV)
1000
Input impedance (balanced) (Ω)
22 000
Input impedance (single-ended) (Ω)
22 000
Output impedance (balanced) (Ω)
N/A
Output impedance (single-ended) (Ω)
N/A
Max current (A)
N/A
Output power (8Ω) (W)
150
Output power (4Ω) (W)
300
Gain (dBu)
31
Frequency response low +/- 3dB (Hz)
5
Frequency response high +/- 3dB (Hz)
100 000
Signal to Noise Ratio (dB)
114
Total Harmonic Distortion + Noise (0% global feedback) (%)
N/A
Total Harmonic Distortion + Noise (100% global feedback) (%)
0.003
Max power consumption (W)
35
Damping factor
425
Dimensions (mm)
429 x 87 x 368
Weight (kg)
11
Official link
