Integrated amplifiers — Canor Audio TP101 A30

Description, images, technical data and specifications

Canor Audio TP101 A30
Image source — © Canor Audio

The TP101 A30 is a distinctive tube integrated amplifier from Canor Audio, built with a wide top-end extension and a comparatively low damping factor typical of tube-informed design. The TP101 A30 brings Canor's most storied engineering heritage to a substantial tube integrated chassis.

Key specs that matter

Input sensitivity is 380mV, with input impedance at 30 ohms single-ended. Output power is 2 x 35W into both 8 and 4 ohms - a modest, characterful tube-amplifier figure. Gain is 33dB at 8 ohms. Frequency response spans a wide 18Hz to 55,000Hz within plus-or-minus 3dB. Signal-to-noise ratio exceeds 96dB, with total harmonic distortion plus noise under 0.025% at 8 ohms. Damping factor is a comparatively low 6.5 at 4 ohms - a specification approach typical of tube-informed designs prioritising harmonic character over damping. At 450 x 185 x 390mm and 23kg, the TP101 A30 represents a substantial commitment reflecting Canor's most storied tube-informed engineering heritage.

Sound and use context

Expect the warm, richly textured character tube amplification is broadly celebrated for, with the wide 18Hz-55kHz bandwidth combined with the strong over-96dB signal-to-noise figure.

Pairing

Canor's own source catalogue offers natural, brand-coherent pairings within the same broader catalogue.

Alternatives

Canor's own Virtus I4S offers a solid-state alternative within the same broader integrated amplifier catalogue.

Specifications

  • Model name

    TP101 A30

  • Type

    Tube Integrated Amplifier

  • Analog inputs (balanced)

    N/A

  • Analog inputs (single-ended)

    N/A

  • Input sensitivity (mV)

    380

  • Input impedance (balanced) (Ω)

    N/A

  • Input impedance (single-ended) (Ω)

    30

  • Output impedance (balanced) (Ω)

    N/A

  • Output impedance (single-ended) (Ω)

    N/A

  • D/A conversion

    N/A

  • Phono MM/MC current-sensing input impedance (Ω)

    N/A

  • Output power (8Ω) (W)

    2 x 35

  • Output power (4Ω) (W)

    2 x 35

  • Gain (dBu)

    33 dB (at 8 Ω)

  • Frequency response low +/- 3dB (Hz)

    18

  • Frequency response high +/- 3dB (Hz)

    55 000

  • Signal to Noise Ratio (dB)

    >96

  • Total Harmonic Distortion + Noise (%)

    < 0.025 % / 8 Ω

  • Damping factor

    6.5 / 4 Ω

  • Dimensions (mm)

    450 x 185 x 390

  • Weight (kg)

    23
