Integrated amplifiers — Advance Paris Nova A-i190
Description, images, technical data and specifications
Advance Paris Nova A-i190
Image source — © Advance Paris
The Advance Paris Nova A-i190 amplifier takes this idea further. A "double mono" circuit with two toroidal transformers in the power supply is used here, so that the channels are virtually completely isolated from each other. At the same time, the older model offers a power of 190 watts per channel with a large dynamic margin.
Specifications
Model name
Nova A-i190
Type
Integrated Amplifier
Analog inputs (balanced)
2
Analog inputs (single-ended)
8
Input sensitivity (mV)
N/A
Input impedance (balanced) (Ω)
N/A
Input impedance (single-ended) (Ω)
N/A
Output impedance (balanced) (Ω)
N/A
Output impedance (single-ended) (Ω)
N/A
D/A conversion
Yes
Phono MM/MC current-sensing input impedance (Ω)
N/A
Output power (8Ω) (W)
195
Output power (4Ω) (W)
297
Gain (dBu)
N/A
Frequency response low +/- 3dB (Hz)
20
Frequency response high +/- 3dB (Hz)
80 000
Signal to Noise Ratio (dB)
105.1
Total Harmonic Distortion + Noise (%)
0.042
Damping factor
N/A
Dimensions (mm)
43x19,2x45,4
Weight (kg)
23.1
Official link
