Cayin Jazz 100
Image source — © Cayin

Voltage amplification is handled by NOS Mullard 6JC6 tubes and a Slovak JJ 6SN7. The driver stage of our test sample ran Electro-Harmonix 6L6EH tubes. Tube rolling is fully sanctioned - EL34, 6CA7, 5881, 6550, KT88 and KT90 all fit, so the amplifier's sonic signature can be tailored to taste. The output stage runs Cayin's own branded 805A directly heated triodes. EI-core output transformers realize the tubes' potential, while a toroidal transformer handles the power supply (maximum consumption reaches 410 W).

Specifications

  • Model name

    Jazz 100

  • Type

    single-ended tube integrated amplifier with DAC

  • Analog inputs (balanced)

    N/A

  • Analog inputs (single-ended)

    3

  • Input sensitivity (mV)

    320

  • Input impedance (balanced) (Ω)

    N/A

  • Input impedance (single-ended) (Ω)

    100000

  • Output impedance (balanced) (Ω)

    N/A

  • Output impedance (single-ended) (Ω)

    N/A

  • D/A conversion

    N/A

  • Phono MM/MC current-sensing input impedance (Ω)

    N/A

  • Output power (8Ω) (W)

    N/A

  • Output power (4Ω) (W)

    N/A

  • Gain (dBu)

    N/A

  • Frequency response low +/- 3dB (Hz)

    12

  • Frequency response high +/- 3dB (Hz)

    33000

  • Signal to Noise Ratio (dB)

    N/A

  • Total Harmonic Distortion + Noise (%)

    N/A

  • Damping factor

    N/A

  • Dimensions (mm)

    420 × 389 × 248

  • Weight (kg)

    35

  • Official link

    https://en.cayin.cn/features/8/57/161/715.html
