Integrated amplifiers — Trafomatic Audio Experience Two MK II

Name: Experience Two MK II
Brand: Trafomatic Audio
Rating: 100 (1 reviews)

Description, images, technical data and specifications

Trafomatic Audio Experience Two MK II
Image source — © Trafomatic Audio

Tube integrated amplifier, output power: 2 x 8 W (single-stroke Class A), frequency range: 10 Hz - 65 kHz, harmonics: 0.55% (1 W), signal-to-noise ratio: 80 dB, input impedance: 100 kOhm, lamp configuration: 2 x 300B, 2 x 6SN7, 1 x 5U4G.

Specifications

Model name
Experience Two MK II
Type
Integrated Amplifier
Analog inputs (balanced)
N/A
Analog inputs (single-ended)
4
Input sensitivity (mV)
500
Input impedance (balanced) (Ω)
N/A
Input impedance (single-ended) (Ω)
100 000
Output impedance (balanced) (Ω)
N/A
Output impedance (single-ended) (Ω)
N/A
D/A conversion
N/A
Phono MM/MC current-sensing input impedance (Ω)
N/A
Output power (8Ω) (W)
2 x 8
Output power (4Ω) (W)
N/A
Gain (dBu)
N/A
Frequency response low +/- 3dB (Hz)
10
Frequency response high +/- 3dB (Hz)
65 000
Signal to Noise Ratio (dB)
80
Total Harmonic Distortion + Noise (%)
0.55
Damping factor
N/A
Dimensions (mm)
450 × 350 x 230
Weight (kg)
24
Official link
https://www.trafomaticaudio.com/products/experience-two-mk-ii/?portfolioCats=13#
