Integrated amplifiers — BC Acoustique EX-214

Specifications

• Model name

  EX-214

• Type

  INTEGRATED AMPLIFIER 2X45W - BLUETOOTH

• Analog inputs (balanced)

  N/A

• Analog inputs (single-ended)

  2 + 1 (Phono)

• Input sensitivity (mV)

  N/A

• Input impedance (balanced) (Ω)

  N/A

• Input impedance (single-ended) (Ω)

  47 000 (Phono)

• Output impedance (balanced) (Ω)

  N/A

• Output impedance (single-ended) (Ω)

  N/A

• D/A conversion

  Yes

• Phono MM/MC current-sensing input impedance (Ω)

  N/A

• Output power (8Ω) (W)

  2 x 45

• Output power (4Ω) (W)

  2 x 70

• Gain (dBu)

  45 (Phono)

• Frequency response low +/- 3dB (Hz)

  20

• Frequency response high +/- 3dB (Hz)

  20 000

• Signal to Noise Ratio (dB)

  >100

• Total Harmonic Distortion + Noise (%)

  < 0,01

• Damping factor

  N/A

• Dimensions (mm)

  430 x 60 x 245

• Weight (kg)

  5.72

• Official link

  https://www.bc-acoustique.com/electronics/integrated-amplifiers/ex-214.html
