Integrated amplifiers — Creek Audio 4040 A
Description, images, technical data and specifications
Creek Audio 4040 A
Image source — © Creek Audio
The 4040 A is a compact integrated amplifier with built-in DAC from Creek Audio, built into a remarkably lightweight chassis with an exceptional damping factor. The 4040 A brings Creek Audio's considered engineering to a space-efficient, accessible integrated format.
Key specs that matter
One balanced XLR input and two single-ended inputs are provided. Input sensitivity is 525mV. Output power is 55W into 8 ohms, rising to 110W into 4 ohms. Gain is 32dBu. Frequency response spans a wide 5Hz to 50,000Hz within plus-or-minus 3dB. Signal-to-noise ratio is 105dB, with total harmonic distortion plus noise under 0.045%. Damping factor exceeds an exceptional 100. At a remarkably compact 215 x 60 x 255mm and just 2.2kg, the 4040 A maintains a space-efficient, lightweight integrated amplifier chassis.
Sound and use context
Expect exceptionally clean, tightly controlled amplification reflecting the exceptional over-100 damping factor combined with the strong 105dB signal-to-noise figure, packed into this remarkably compact, lightweight chassis.
Pairing
The built-in DAC covers digital sources directly without needing a separate outboard converter.
Alternatives
Creek Audio's own Voyage i20 offers a considerably more powerful alternative within the same broader integrated amplifier catalogue.
Key specs that matter
One balanced XLR input and two single-ended inputs are provided. Input sensitivity is 525mV. Output power is 55W into 8 ohms, rising to 110W into 4 ohms. Gain is 32dBu. Frequency response spans a wide 5Hz to 50,000Hz within plus-or-minus 3dB. Signal-to-noise ratio is 105dB, with total harmonic distortion plus noise under 0.045%. Damping factor exceeds an exceptional 100. At a remarkably compact 215 x 60 x 255mm and just 2.2kg, the 4040 A maintains a space-efficient, lightweight integrated amplifier chassis.
Sound and use context
Expect exceptionally clean, tightly controlled amplification reflecting the exceptional over-100 damping factor combined with the strong 105dB signal-to-noise figure, packed into this remarkably compact, lightweight chassis.
Pairing
The built-in DAC covers digital sources directly without needing a separate outboard converter.
Alternatives
Creek Audio's own Voyage i20 offers a considerably more powerful alternative within the same broader integrated amplifier catalogue.
Specifications
Model name
4040 A
Type
Integrated Amplifier with DAC
Analog inputs (balanced)
1
Analog inputs (single-ended)
2
Input sensitivity (mV)
525
Input impedance (balanced) (Ω)
N/A
Input impedance (single-ended) (Ω)
N/A
Output impedance (balanced) (Ω)
N/A
Output impedance (single-ended) (Ω)
N/A
D/A conversion
Yes
Phono MM/MC current-sensing input impedance (Ω)
N/A
Output power (8Ω) (W)
55
Output power (4Ω) (W)
110
Gain (dBu)
32
Frequency response low +/- 3dB (Hz)
5
Frequency response high +/- 3dB (Hz)
50 000
Signal to Noise Ratio (dB)
105
Total Harmonic Distortion + Noise (%)
<0.045
Damping factor
>100
Dimensions (mm)
215 x 60 x 255
Weight (kg)
2.2
Official link
